Ankle & Foot Diagnostic Imaging Arthritis & Trauma II| El Paso, TX.

Lisfranc Fracture-Dislocation

• M/C dislocation of the foot at tarsal-metatarsal articulation (Lisfranc joint). Direct impact or landing and plantar or dorsal flexing the foot. Lisfranc ligament holding 2nd MT base and 1st Cu is torn. Manifests with or w/o fracture-avulsion.
• Imaging: 1st step: foot radiography in most cases sufficient to Dx. MSK US may help: show disrupted Cu1-Cu2. ligament and widened space > 2.5mm. MRI may help but not essential. Weight-bearing view aids Dx.
• 2-types: homolateral (1st MTP joint i contact) and divergent (2-5 MT displaced laterally and 1st MT medially)
• Management: operative fixation is crucial
• N.B. Atraumatic Lisfranc dislocation is a frequent complication of a diabetic Charcot foot

Osteochondral Injury of the Talus (OCD)

• Common. Non-traumatic found in superior-medial talar dome. Traumatic may affect supero-lateral dome.
• Clinically: pain/effusion/locking. Imaging is crucial.
• 1st step: radiography may reveal focal radiolucent concavity/halo, fragment.
• MRI helpful esp. if OCD is cartilaginous and to demonstrate bone edema.
• Management: non-operative: short-leg cast/immonbilization-4-6 wk. operative: arthrocsopic removal.
• Complications: premature 2nd DJD

Metatarsal Injuries

• Acute & Stress fractures are common: m/c 5th MT & 2nd, 3rd MT.
• Jones Fx: extra-articular Fx of proximal metaphysis of the 5th MT. prone to non-union. Often fixed operatively.
• Pseudo-Jones: intra-articular avulsion of 5th MT styloid/base by eccentric contraction of Peroneus brevis M. Managed conservatively: boot-cast immonbilization. Both Jones & Pseudo-Jones Dx by foot series radiography.
• Stress Fx. Calcaneus, 2nd, 3rd, 5th MTs. Repeated loading (running) or “March foot” 2nd/3rd MT. Clinically: pain on activity, reduced by rest. Dx: x-rays often unrewarding earlier. MRI or MSK US may help. Managed: conservatively. Complications; progress into complete Fx
• Turf toe: common athletic hyperextension of 1st MTP-sesamoid/plantar plate complex tearing. 1st MTP unstable/loose. Managed operatively.

Arthritis of the Foot & Ankle

• DJD of the ankle: uncommon a sprimary OA. Typically develops as 2nd to trauma/AVN, RA, CPPD, Hemophilic arthropathy, Juvenile Idiopathic Arthritis etc. manifests as DJD: osteophytes, JSL, subcohnodral cysts all seen on x-rays
• Infalmmatory Arthritis: RA may develop in the ankle or any synovial joint. Will typically  presents with symmetrical Hands/feet RA initially (2nd, 3rd MCP, wrists, MTPs in feet) typically with erosion, iniform JSL, juxta-articular osteopenia and delayed subluxations.
• HLA-B27 spondyloarthropathies: commonly affect lower extremity: heel, ankle esp in Reactive (Reiter). Erosive-productive bone proliferation is a key Dx.
• Gouty Arthritis: common in the lower extremity. Ankle, mid-foot foot esp 1st MTPs. Initial onset: acute gouty arthritis with ST effusion and no erosions/tophi. Chronic tophacious gout: peri-articular, intra-osseous punched-out erosions with over-hanging edges, no initial JSL/osteopenia, ST. tophi may be seen.
• Miscellaneous arthropathy: PVNS. Not common. Affects 3-4th decades of life. The result of synovial proliferation with Machrophages and multi-nucleated Giant Cells filled with hemosiderin and fatty accumulation, may lead to inflammation, cartilage damage, extrinsic bone erosions. Dx: x-rays are insensity, MRI modality of choice. Synovial biopsy. Management: operative, can be difficult.

Neuropathic Osteoarthropathy

• (Charcot joint) Common and on the rise d/t epidemic in type 2 DM. May present with pain initially (50% of cases) and painless destructive arthropathy as late manifestation. Early Dx: delayed. Imaging is crucial: x-rays: initially unrewarding, some SF effusion is seen. MRI helps with early Dx and extremity off-loading. Late Dx: irreversible dislocations, collapse, disability. Note: Lisfrance dislocation in Charcot joint
• M/C mid-foot (TM joint) in 40% of cases, ankle 15%. Progression: Rocker-bottom foot, ulcerations, infections, increased morbidity and mortality.
• Early Dx: by MRI is crucial. Suspect it in patients with type 2 DM especially if early non-traumatic foot/ankle pain reported.
